$60.00
| - Capable of supplying1-2 fixture. - 18AWG,13?long Leads. - Ignition protected. - Meets or exceeds RoHS, SGS, and ISO standards. | - Intermittent duty. - Industry standard mounting pattern. - 2 Year Warranty. |
.gif)
| PUMP | |
| Type | 2 Chamber positive displacement diaphragm pump, self priming, capable of being run dry |
| Control Type | Pressure switch |
| Max Recommended Temperature | 60° C (140° F) |
| Priming Capabilities | 4 feet (1.2 m) suction lift |
| Re-start Pressure | Shut-off Pressure 35 PSI: 25 PSI ±5 PSI (±0.3 bar) Shut-off Pressure 40 PSI: 30 PSI ±5 PSI (±0.3 bar) Shut-offPressure 70 PSI: 56 PSI ±5 PSI (±0.3 bar) |
| Inlet/Outlet Ports | 3/8" (10 mm) hose barb |
| Weight | 1.3 lbs (0.6 kg) |
| MOTOR | |
| Leads | 18 AWG, 14" (35 cm) long with 2-Pin connector / Leads |
| Duty Cycle | Intermittent |
| Max.Amp Draw | 4.0 A |
| Fuse | 6.0 A |
| Model | Voltage | Open Flow ?GPM/LPM? | Control Type | Max Draw | Shut-off Pressure ?PSI/BAR) | Valves | Diaphragm | Ports | Wire Connections |
| SFDP1-010-040-21 | 12V | 1.0 / 3.8 | Switch | 4.0A | 40 / 2.8 | EPDM | Santoprene | 3/8" Barb | 2-Pin/Leads |
| SFDP2-010-040-21 | 24V | 1.0 / 3.8 | Switch | 2.0A | 40 / 2.8 | EPDM | Santoprene | 3/8" Barb | 2-Pin/Leads |
1.0 GPM
|
||||||||||||||||||||||||||||||||||||
.jpg)
DIMENSIONS
.jpg)
View Instruction Manual
