$240.85
| -Can supply up to 4 fixtures -Precise pressure control and stable performance -Good sealing performance,waterproof and dustproof -Low starting pressure,reduces cycling -Good heat dissipation | -Run dry safe -Can be use for Fresh&Salt Water -2 Year Warranty - Meets or exceeds RoHS, SGS, and ISO standards |
.jpg)
Marine,RV,Agricutural Spraying,General Industial,Filtration,Beverage Processing,Solar Water System.
| PUMP | |
| Type | 5 Chamber positive displacement diaphragm pump, self priming, capable of being run dry |
| Control Type | Pressure switch |
| Max Recommended Temperature | 60° C?140° F? |
| Priming Capabilities | 6 feet (1.8 m) suction lift |
| Re-start Pressure | Shut-on Pressure 20 PSI ?20 PSI ±3 PSI Shut-off Pressure 60 PSI ?60 PSI ±3 PSI |
| Inlet/Outlet Ports | 1/2"-14 MNPT |
| Weight | 6.1 lbs (2.8 kg) |
| MOTOR | |
| Leads | 14 AWG, 13" (33 cm) long with 2-Pin connector / Leads |
| Duty Cycle | Continuous |
| Max.Amp Draw | 17.0 A |
| Fuse | 25.5 A |
| Model | Voltage | Open Flow ?GPM/LPM? | Control Type | Max Draw | Shut-off Pressure ?PSI/BAR) | Valves | Diaphragm | Ports | Wire Connections |
| SFDP1-050-060-51 NEW | 12V | 5.0 / 18.9 | switch | 15.0A | 60 / 4.2 | EPDM | Santoprene | 1/2"-14 MNPT | 2-Pin/Leads |
2.8 GPM
.jpg)
|
|||||||||||||||||||||||||||||||||||||||||
.jpg)
| Key | Description | Quantity |
| A | Pump Head Assembly | 1 |
| B | Valve Assembly | 1 |
| C | Diaphragm Assembly | 1 |
| D | Motor Assembly | 1 |
| 1 | Pressure switch | 1 |
| 2 | Diaphragm of Pressure Switch | 1 |
| 3 | Pump Head | 1 |
| 4 | Diaphragm | 1 |
| 5 | Rubber Feet | 1 |
| 6 | Motor | 1 |
